|LCD Panel Resolution|
|LCD panel size|
Fashionable Design. Metal body, aluminum materia
Easy to change customer display or 2nd screen without screwdriver.
Easy to install MSR, Ibutton.
Easy to replace 2.5″ hard disk without opening the whole machine.
Light body, save roomsStand back cover can hide the wire.
High standard of waterproof and dustproof (P54)
IO panel is on the top, which is convenient to find the corresponding port
|CPU||Intel Bay Trail-D processors J4125 QUAD 2.0G|
|Chipset||Intel Bay Trail-D|
|OS Support||Windows 7, windows 10 ,Linux|
|Resolution||1024 x 768|
|Touch Screen||Capacitive touch screen|
|Tilting Angle||35-90 Degree|
|SSD||64G/128G SSD MSTAT OR,2.5″ SATA|
|SATA Slot||1 x mSATA Slot|
|Serial||2 x COM with Power Selected 5/12V (COM 2/3), Selected by Jumper,1 x COM without Power Output (COM 1),COM2 is Customer Display|
|USB||6 x USB 2.0 (External),2x USB 2.0,(Internal, reserved for touch screen,MSR)|
|LAN||1 x RJ-45, Giga LAN|
|VGA||1 x DB-15, Female|
|DC Out||Optional:1 x +12VDC Jack (Customer Display or 2nd Display)|
|Audio Jack||1 x Line Out, 1 x MIC In,1 x Internal Speaker|
|Optional||MSR,RFID,Fngerprint,2*20 VFD customer display,10.1 inch customer display|
Dongguan Tcang Electronics Co., Ltd. was established in 2010, located in Dongcheng District, Dongguan City, Guangdong Province, China. The company mainly designs, develops and produces POS equipment. The main products are 5.5 inch handheld POS machine, 12 inch POS system, 15 inch all-aluminum body POS and 15.6 inch ultra-thin POS terminal.
As a professional pos hardware manufacturer, Tcang has long been committed to providing customers with safe, high-quality, cost-effective POS systems, and offers a variety of customized services to meet customer requirements.
